Gautam tubes is a prominent exporter and supplier of Stainless Steel 316L Sheets and Plates. We are an ISO accredited company supplying products under national and international standards. Stainless steel flanges have excellent features that meet the requirements of our customer's end applications. 316L sheets and plates are accepted in wide engineering sectors and mainly used in heat processing industries.
Our offered range of sheets and plates are supplied in different specifications, designations, custom dimensions and non-standard dimensions too. We have a large production facility which is equipped with latest machinery and equipment to drive production in utmost quality.
Stainless Steel 316L Sheets and Plates are molybdenum containing austenitic stainless steel sheets and plates mostly used to provided corrosion resistance relative to 300 series grades in moderately corrosive environments. These are also used in environments having halides and chlorides. Type SS 316L is non-magnetic in nature when annealed, but turns slightly magnetic after welding operations.
It is general for type 316L grades to be dual certified when materials meet lower and higher carbon limit and strength of 316. This depends on the end application requirements of customers.
316L SS Coils, SS 316L 2B Finish Sheets, Austenitic Stainless Steel 316L Perforated Sheets Distributors, Stainless Steel 316L Sheets Price List, Stainless Steel 316L Hot Rolled Plates, ASTM A240 SS 316L Sheets & Plates Exporter in India.
In addition to molybdenum in 316L grade, it gets improved resistance to crevice and pitting corrosion in moderate to concentric environments. SS 316L Sheets and plates have been used in handling various chemicals encountered in the process industries. Chemicals like acetic acids, phosphoric acids, nitric acids, and sulfuric acids do not affect these sheets and plates.
Annealing of type 316 sheets and plates are performed temperatures up to 1900 deg F and water quenched or other means rapidly. Stainless steel sheets and plates are suitable for heading, drawing, bending, and upsetting. Hardening cannot be done by heat treatment operations, only cold working is recommended. 316L sheets and plates are readily formed and fabricated through a full range of cold working process.
The cold working operations will increase the hardness and strength of materials. Hot working is done be between 1700 deg F to 2200 deg F, in same it can be forged. The forging operation should be done at 1900 deg F for maximum corrosion resistance.
Standard Specification and Size Range of Stainless Steel 316L Sheets & Plates
Specifications : ASTM A240 / ASME SA240
Dimensions : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
ASTM A240 316L SS Perforated Sheets
SS 316L Perforated Sheet, Stainless Steel 316L Perforated Sheets, UNS S31603 Perforated Sheets, DIN 1.4404 Perforated Sheets, Stainless 316L Perforated Sheets
ASTM A240 316L SS Chequered Plates
Stainless Steel 316L Chequered Plates, SS 1.4404 Chequered Plates, UNS S31603 Chequered Plates, SS 316L Checkered Plates
ASTM A240 316L SS Shim Sheets
Stainless Steel 316L Shim Sheets, SUS 316L Shim Sheets, SS S31603 Shim Sheets, DIN 1.4404 Shim Sheets
Chemical Composition of Stainless Steel Grade 316L Sheets & Plates
|SS 316L||0.035 max||2.0 max||1.0 max||0.045 max||0.030 max||16.00 - 18.00||2.00 - 3.00||10.00 - 14.00||68.89 min|
Mechanical Properties of ASTM A240 SS 316L Sheets & Plates
|Density||Melting Point||Tensile Strength||Yield Strength (0.2%Offset)||Elongation|
|8.0 g/cm3||1399 °C (2550 °F)||Psi – 75000 , MPa – 515||Psi – 30000 , MPa – 205||35 %|
People Also Searched For
type 316l ss sheets price, ss 316l checker plates, sus 316l hot rolled plates, asme sa 240 stainless steel 316l plates, astm a240 316l stainless steel sheets dimensions, schedule 10 stainless steel 316l 2b finish plates, ss 316l coil stockholder, ss 316l coils, astm a240 ss 316l sheets manufacturer in mumbai, 316l stainless steel plates, buy best and high quality stainless steel 316l sheets at competitive price, ss 316l slit coils, astm a240 316l plates supplier in india, astm a240 316l sheet, astm a240 316l strips price list, stainless steel 316l sheets stockholder, ss 316l plain sheet, stainless steel 316l sheets supplier, grade 316l stainless steel perforated sheets, ss 316l slitting coils, stainless steel 316l sheet / plate / coil, price of sheets and plates stainless steel 316l, ss 316l foils, 316l ss coils, 316l stainless steel perforated sheets traders, stainless steel 316l mirror sheet, stainless steel 316l ba finish cold rolled sheet manufacturers in india, aisi 316l cold rolled sheets, ss 316l plates, ss 316l hot rolled plates exporter in india, ss 316l sheets dealers, stainless steel 316l circle.
Oil and Gas
- Grade 316L Stainless Steel Sheets uses in Plumbing
- ASTM A240 316L Stainless Steel Plates uses in Heating
- ASTM A240 316L Sheets uses in Water Supply Systems
- SS 316L Coil uses in Paper & Pulp Industry
- 316L SS Plates uses in General Purpose Applications
- ASME SA240 Stainless Steel 316L Sheets uses in Fabrication Industry
